PRODUCT FEATURES
- Cast brass body
- Vandal-resistant ADA lever handle
- Metering, slow-close lever
- Red/blue indicators
- 2.38" max deck thickness
- Vandal-resistant spray outlet
- Vandal-resistant non-aerating spray outlet
- 2.38" max deck thickness
- Delta® metering slow-close cartridge
Technology and Special Features
ADA Compliant
ADA Compliant
Some people, and some local codes, require fixtures that are compliant with the Americans with Disabilities Act. If someone may visit who has special needs, or if you believe future buyers might appreciate this feature, Delta offers a range of compliant fixtures.
No-Lead Compliant
No-Lead Compliant
Tested and certified to NSF/ANSI Standard 61, which sets the criteria for product safety. The lined waterways in Delta® faucets help prevent leaching of metals.
Water-Efficient
Water-Efficient
CalgreenCert Tooltip information here...
Documents & Specs
Product Support, Repair Parts & Technical Specifications
Installation Information
Connection Type :
3/8" compression fittings
Flow Rate :
0.50 gpm @ 60 psi, 1.9 L/min @ 414 kPa
Overall Height (in.) :
3-3/4
Control Box Option:
N/A
Installation Center:
4" (102mm) Centers
Mounting:
Deckmount
Valve Type:
NA
INSTALLATION SUPPORT
Need help with installation? Mike & Hannah are here to help! Get advice from the pros on everything from installation to product care.
